Chapter 7: Support & Integration

7.1 Supporting System Integration Ecosystem

The following diagram illustrates all eight supporting systems that integrate with the wireless security platform, along with the protocols, ports, and data flows for each integration. All eight systems are essential for a complete enterprise wireless security deployment — the absence of any single integration creates a security gap that adversaries can exploit.

Figure 7.1: Wireless Security Platform — Integrated Support Ecosystem with Eight Supporting Systems, Protocols, and Data Flows

7.2 Supporting System Integration Details

7.2.1 Active Directory / LDAP

The RADIUS server integrates with Active Directory (or any LDAP-compatible directory) to perform user and group lookups during 802.1X authentication. When a user authenticates, the RADIUS server queries AD to verify credentials (for EAP-TTLS/PEAP) or retrieve group membership (for EAP-TLS). Group membership is used to determine VLAN assignment and access policy. The integration uses LDAPS (TCP 636) with mutual TLS to protect directory queries in transit.

7.2.2 PKI / Certificate Authority

The PKI infrastructure issues and manages all certificates used in the wireless security system: server certificates for RADIUS and WLAN Controller, client certificates for EAP-TLS authentication, and CA certificates distributed to all supplicants for server validation. The RADIUS server queries the OCSP responder in real time during each EAP-TLS authentication to verify that the client certificate has not been revoked. CRL distribution points serve as a fallback when OCSP is unavailable.

7.2.3 MDM / UEM Integration

Mobile Device Management (MDM) or Unified Endpoint Management (UEM) platforms integrate with the wireless security system in two critical ways: certificate provisioning and device posture enforcement. MDM pushes 802.1X supplicant configuration and client certificates to all managed devices via over-the-air enrollment, ensuring consistent and correct supplicant settings without manual user configuration. MDM also provides device posture data to the NAC platform — OS version, patch level, encryption status, jailbreak detection — which is used to determine the appropriate VLAN assignment.

7.2.4 SIEM / SOC Integration

All wireless security events — authentication successes and failures, WIPS alerts, rogue AP detections, policy violations, and administrative actions — are forwarded to the SIEM in real time via Syslog (UDP 514 or TCP 6514 with TLS). The SIEM correlates wireless events with events from other security systems (firewall, endpoint, identity) to detect complex attack patterns that span multiple systems. Key correlation rules include: multiple authentication failures followed by a successful login (credential stuffing), a new device appearing on the network immediately after a deauth flood (evil twin attack), and an IoT device attempting to communicate with an unexpected destination (compromise indicator).

7.2.5 NAC Platform

The Network Access Control platform enforces dynamic access policies based on device identity, user identity, device posture, and time-of-day. The NAC integrates with the RADIUS server via RADIUS Change of Authorization (CoA, UDP 3799) to dynamically modify a client's VLAN assignment or quarantine a device without requiring re-authentication. This enables real-time response to security events: when the MDM reports that a device has become non-compliant (e.g., OS update required), the NAC sends a CoA to move the device to a restricted VLAN until remediation is complete.

7.2.6 IPAM / DHCP / DNS

IP Address Management (IPAM) integration provides the wireless security system with visibility into IP-to-MAC-to-user mappings, enabling accurate attribution of network events to specific devices and users. DHCP snooping on PoE switches prevents rogue DHCP servers from operating on the wireless network. DNS filtering (integrated with the Guest and IoT VLANs) blocks resolution of known malicious domains, C2 servers, and inappropriate content categories.

7.3 Integration Requirements Summary
